Technical problems and their resolution

Creaking after anti-termite treatment..

7 replies 903 views

Started by

foster12

Member

Member

Opening post by foster12

Posts
376
City
Milano

Good morning everyone.

I am asking for your opinion regarding this creaking sound that can be heard when I press the forte pedal, as shown in the video below.

I am adding two elements:

1) it is strictly related to the upper part (and not to the pedal). It originates from the contact between the horizontal steel rod and the contact with the damper felts, as seen in the first part of the video below.

2) it began to manifest when I inserted one of these Tarmiblock moth repellent sachets (image attached) inside the action.

Any experiences regarding this?

Thank you


Moderator

Reply 2 by pianoexpert

Posts
3,876
City
rocca di papa

by "eye and cross" [guesswork], it doesn't seem to me to depend on the mechanics. It could be the damper lift bar itself. Once the bar has been degreased (by removing the small supports, one of which is "left-handed" and degreasing it) If it still does it, I would apply a little DRY TEFLON spray between the bar and the felt of the damper rests. DO NOT USE GREASY LUBRICANTS!!!!!!!!!!!!! If, by any chance, they have been used in the past....this could be the cause. I don't think it depends on the anti-moth treatment.

Anyway, the anti-moth treatment must not be used. When you play, the moth does not live!!!! only if the instrument is inactive for very long periods of time

Member

Reply 3 by foster12

Posts
376
City
Milano

Thank you Maestro.

However, I wanted to understand how to apply the graphite. Do I use a small brush and apply it to both the metal and the felt?

Unfortunately, living in quite a wild area, I have to deal with all kinds of dangers. Starting with these absolutely foul carpet beetles that are also fond of felt.

https://pictureinsect.com/it/wiki/Anthrenus_verbasci.html

https://pictureinsect.com/it/wiki/Anthrenus_verbasci.html

Member

Reply 5 by foster12

Posts
376
City
Milano

I would like to share the resolution of this problem.

In essence, a very skilled technician (Maestra C@viglia) identified the cause in the clip/felts no. 27 of this diagram.

https://ibb.co/Pj8L57w

[url=https://ibb.co/Pj8L57w][img]https://i.ibb.co/NCzvL8Z/Screenshot-20240718-161548.jpg[/img][/url]

To resolve it, she applied injections of specific lubricant.

Therefore, I have closed the matter.

https://ibb.co/Pj8L57w

Member

Reply 6 by francescochopin90

Posts
355
City
.

Those "injections" of lubricant (grease!!!) work instantly, but the problem resurfaces with interest. It is always better to use dry lubricants, but only to facilitate and optimize mechanics that are already working well. Otherwise, they are just a palliative: friction problems must be solved at the source by searching for the cause.

Member

Reply 8 by foster12

Posts
376
City
Milano

In case I wanted to try, do you have a teflon spray that you recommend? Are they already equipped with a directional straw?
